LS163 Transmission Meter

LS163 Transmission Meter

Details

I. LS163 Transmission Meter Introduction

Linshang LS163 is both a transmission meter and a portable transmittance meter. The instrument can test three parameters of visible light, infrared and ultraviolet. This solar film transmission meter has three different display modes, which are light transmittance display, rejection rate display and light transmission display. It is a versatile portable test instrument. The following is a video introduction of the LS163 solar film tester (Note: LS163 and LS163A have the same characteristics. The video uses LS163A as an example to explain)

LS163 advantages video

II. LS163 Transmission Meter Application

LS163 solar film transmission meter is widely used in solar film, glass industry, automobile 4S shops, beauty shops, etc. It is suitable for display, production, quality inspection, inspection and other occasions. It can test optical properties of solar film, stick-film glass, PC material and window glass.

LS163 window tint detector test different materials
LS163 window tint detector test different materials

III. LS163 Transmission Meter Parameters

UV Peak wavelength 365nm
IR Peak wavelength 940nm
Visible light wavelength 380-760nm, conform to the CIE photopic luminosity function
Accuracy ±2% (Colorless and transparent material)
Resolution 0.1%
Test Slot 6mm * 58mm (W*D)
Dimension 146 mm ×73 mm ×24 mm (L*W*H)
Display 128*128 Dot matrix LCD
Weight 187g (Include Batteries)
Power supply 4*AAA alkaline battery

IV. LS163 Transmission Meter Characteristics

1. The solar film transmission meter has simple operation and fast measurement. The three test results will be displayed on the interface immediately after putting the materials into the test slot.

LS163 window tint meter test stick-film glass
LS163 window tint meter test stick-film glass

2. The LS163transmission meter adopt parallel light path design, the test slot width can be 6mm. The instrument can also test car side windshield.

LS163 transmission meter test the car side windshield
LS163 transmission meter test the car side windshield

3. The display interface can be rotated 360 ° adaptively, which is convenient for reading data when testing at different angles.

LS163 window tint meter rotative interface
LS163 window tint meter rotative interface

4. The LS163 solar film transmission meter has real time dynamic calibration function , the meter will make self-calibration after power on.

LS163 window tint meter pass self-calibration
LS163 window tint meter pass self-calibration

5. We can set the display data as rejection rate or light transmittance. The instrument can also only display the visible light transmittance.

LS163 window tint meter three measurement interfaces
LS163 window tint meter three measurement interfaces

6. The window tint detector has data lock function. Press the hold button after testing, the data will remain on the interface after taking away the tested materials.

LS163 tint tester data lock function
LS163 tint tester data lock function

7. The window film transmission meter has small size with anti-slip design. The anti-slip design is convenient for holding or carrying out.

small size LS163 transmittance meter
small size LS163 transmittance meter

8. The instrument adopts LCD dot matrix screen with backlight, which can be used in dark environment.

9. The tint tester is powered by 4 AAA alkaline dry batteries with low power consumption. It can continuously measure for more than 100 hours. The meter will automatically shutdown without operation after 3 minutes.

V. LS163 Transmission Meter Qualification

solar film tester patent certificate
solar film tester patent certificate

VI. LS163 Transmission Meter Operation Video

VII. LS163 Transmission Meter Packaging Details

No. Description Quantity Unit
1 LS163 Transmission Meter 1 set
2 User Manual 1 pcs
3 AAA Battery 4 pcs
4 Certificate / Warranty Card 1 pcs
5 Drawstring Bag 1 pcs
6 Packing box dimension 18*13*5 cm(L*W*H) 1 pcs
LS163 Transmission Meter package
LS163 Transmission Meter package

VIII.LS163 Transmission Meter After-Sales Service

  1. The meter has one-year warranty. If the meter works abnormally, please send the whole meter to the company for maintenance.

  2. Provide users with spare parts and lifelong maintenance services.

  3. Provide the users with the meter inspection service for free.

  4. Free technical support for long term.

Manufacturer: Shenzhen Linshang Technology Co., Ltd.

Website: www.linshangtech.com

Service hotline: 086-0755-86263411

Email: sales21@linshangtech.com

For more information about the Transmission Meter selection, please click article below for details

Window Film Transmission Meter Selection and FAQ.

IX. FAQ about LS163 Transmission Meter

  1. 1. The difference between LS163 (940nm) and LS163A (1400nm) window film transmission meters

    The main difference between LS163 and LS163A is that the peak wavelength of the built-in infrared light source is different, LS163: 940nm, LS163A: 1400nm. These two wavelengths are more representative, most of the absorption film has a better rejection effect at 940nm. The metallic film (insulation by reflecting heat) has a better rejection effect at 1400nm. Please choose the appropriate model according to your own film.

  2. 2. What are the advantages of LS163/LS163A over previous window film transmission meters?

    The screen can rotate in four directions;

    Three display interfaces can be switched:

    1) UV rejection, IR rejection, VL transmittance

    2) UV transmission, IR transmission, VL transmittance

    3) VL transmittance
